Title
Plan, profil, eseulation, et estimation du corps de cazernes ordonne a hesdin. / Dupuy de Mondragon.
Creator
Mondragon, Dupuy de, active 1676-1693, engineer, artist.
Publication details
le 26 Ocbre 1692.
Physical details
1 drawing : pen with black and brown ink and watercolour ; sheet 45.9 x 63.7 cm
Description
Plan, elevation and estimate for barracks at Hesdin. Inscribed with title and signed and dated in brown ink on verso. Isncribed with further title in upper right-hand corner in black ink. Inscribed with extensive estimates in black ink in the upper right-hand corner. Scale bar in black ink in lower left-hand corner.
Place
Hesdin (France)
Additional information
Scale ca. 1: 144. 1 5/6 toise to an inch.
Shelfmark
Maps K.Top.58.87.
