Title
Grund Riss der Schleuse bis zur ersten Quader Lago undihrst Boden : Grand Riss der Schleuse worin die anordnung der Grund stahle mit dem Rest und Anlage der Kernwande zuersehen.
Creator
Dammert, Johann Christian, 1754-1828, artist, engineer.
Publication details
[1785]
Physical details
1 drawing : pen and black ink with monochrome, pink and brown wash ; sheet 58.4 x 90.5 cm
Description
Two ground plans for the sluices on the River Weser, Hamelin. Inscribed with titles in black ink along upper edge and centre. Dated in black ink in the lower left-hand corner. Inscribed 'Tab V' in black ink in the upper right-hand corner. Scale in black ink along the lower edge.
Place
Hameln (Germany)
Additional information
One of six drawings for a dredging machine or sluice at the River Weser, Hamlin, by the hydraulic engineer, Johann Christian Dammert at Maps K.Top.100.69.2.a. - Maps K.Top.100.69.2.f. Maps K.Top.100.69.2.f. is signed by Dammert. Maps K.Top.100.69.2.e. is dated 1785.
Shelfmark
Maps K.Top.100.69.2.e.
