Title
Plan, Elevation & Section of part of the Front of the Barracks proposed to be Built in Hyde Park for his Majesties Foot Guards.
Publication details
[around 1740-1780]
Physical details
1 drawing : pen and ink with monochrome wash ; sheet 49 x 69.2 cm
Description
The elevation, section and plan of part of the barracks for the Foot Guards in Hyde Park (now called the Wellington Barracks). Scale 1: 144. 12 feet to an inch. Bears watermark 'IHS / I VILLEDARY = Ornamented Fleur de Lys / 4 / LVG'.
Place
London (England)
Shelfmark
Maps K.Top.26.6.b.
