PLAN and ELEVATION of the BARRACKS for OFFICERS and SOLDrs Marked ion the GENERAL PLAN C.C. : PLAN SECTION and ELEVATION of the SOLDOERS BARRACKS Marked in the GENERAL PLAN D.D.D.D. ; PLAN SECTION and ELEVATION of the BARRACKS for OFFcrs and STOREKEEPER&c Marked in the GENERAL PLAN B.B. ; PLAN and ELEVATION of the BREWHOUSE BAKEHOUSE and SUTLERY Marked in the GENERAL PLAN F. ; PLAN and ELEVATION of the HOSPITAL and GRANARY Marked in the GENERAL PLAN G. / Received with Mr Skinner's Report & Letter dat from Inverness 30 and 31 May 1747.
Creator
Skinner, William, 1700-1780, artist, architect.
Publication details
30 and 31 May 1747.
Physical details
1 drawing : pen and black ink with watercolour ; sheet 53 x 74.5 cm
Description
Plans, sections and elevations for buildings at the proposed Oliver's Fort. Inscribed with titles across the sheet. Inscribed 'No6' in the upper left-hand corner. Drawn on a scale of 20 feet to an inch. Bears watermark IHS / I VILLEDARY = Ornamented Fleur de Lys / 4 / LVG.
Place
Inverness (Scotland)
Additional information
This drawing is one of eight plans and elevations together with a manuscript estimate and proposal at Maps K.Top.50.9.a.-i. for a fort at Inverness to replace Oliver's Fort which had been damaged in 1745.
