Title
PLAN ELEVATION and SECTION Of the Master Gunners House at CHATHAM with Propos'd Addition. / Estimated at
Publication details
[after 1717]
Physical details
1 drawing : pen and black ink with watercolour ; sheet 26.6 x 32.5 cm
Description
Plan, section and elevation of the Master Gunner's House at Chatham with proposed additions. Inscribed in brown ink in lower left-hand corner by a plan 'Proposed addition'. Inscribed in left-hand edge 'Proposed addition' beneath elevation. Inscribed with title in brown ink in upper right-hand corner.
Place
Kent (England)
Additional information
Scale 1: 96. 8 feet to an inch.
Shelfmark
Maps K.Top.16.42.h.
